Motorola GP series Service Information

VHF PCB 8486101B11 Parts List 4-59
L3301 2462587T35 12nH
L3303 2462587T35 12nH
L3304 2462587T23 470nH
L3305 2462587T35 12nH
L3306 2462587T35 12nH
L3308 2462587T34 10nH
L3309 2462587N55 150nH
L3312 2462587V28 33nH
L3501 2413926H09 5.6nH
L3503 2462587V32 68nH
L3504 2462587N51 68nH
L3511 2462587N44 18nH
L3512 2479990B01 11.03nH
L3513 2479990A02 7.66nH
L3515 2479990C03 13.85nH
L3518 NOTPLACED
L3519 2484657R01 Ferrite Bead
L3521 2479990A02 7.66nH
L3522 2479990E01 23.75nH
L3523 2462587N68 1000nH
L3531 2479990N01 43.67nH
L3532 2479990N01 43.67nH
L3538 2479990M01 30.54nH
L3551 2479990N01 43.67nH
L3552 2479990A02 7.66nH
L3701 2462587Q42 390nH
L3731 2462587Q20 2,200nH
L3801 2462587V34 100nH
L3809 2462587V27 27nH
L3811 2462587V34 100nH
L3812 2462587V34 100nH
L3813 2462587Q47 1000nH
L3816 2462587V34 100nH
L3821 2462587N50 56nH
L3822 2462587N49 47nH
L3823 2462587N49 47nH
L3824 2462587N68 1000nH
L3825 2462587V34 100nH
L3826 2462587N68 1000nH
L3831 2462587N50 56nH
L3832 2462587N51 68nH
L3833 2462587N50 56nH
L3834 2462587N68 1000nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
Circuit
Ref.
Motorola
Part No.
Description
L505 2462587Q42 390nH
L601 NOTPLACED
M100 7585651Z01 EMI Pad
M101 7585651Z01 EMI Pad
M300 7585651Z01 EMI Pad
M301 7585651Z01 EMI Pad
M400 7585651Z01 EMI Pad
M401 7585651Z01 EMI Pad
PB501 4080523Z02 Tactile Switch
PB502 4080523Z02 Tactile Switch
PB503 4080523Z02 Tactile Switch
PB504 4080523Z02 Tactile Switch
PB505 4080523Z02 Tactile Switch
Q3200 4802197J95 NPN Transistor
Q3201 4880214G02 NPN Transistor
Q3202 4880214G02 NPN Transistor
Q3270 4805218N63 RF NPN Transistor
Q3301 4880214G02 NPN Transistor
Q3302 4802197J95 NPN Transistor
Q3501 4813828A08 RF Power Amplifier
Q3561 4813824A17 PNP Transistor
Q3721 4809939C05 DUAL NPN/PNP Transistor
Q3801 4802197J95 NPN Transistor
Q400 4809579E18 MOSFET P-Channel
Q403 4813824A17 NPN Transistor
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 MOSFET P-Channel
Q417 4809939C05 DUAL NPN/PNP Transistor
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R3200 0662057M54 150
R3201 0662057M82 2.2K
R3202 0662057M90 4.7K
R3203 0662057M98 10K
R3204 0662057M26 10
R3205 0662057M74 1K
R3206 0662057N23 100K
R3207 0662057N13 39K
R3208 0662057M50 100
R3209 0662057M74 1K
R3210 0662057M82 2.2K
R3211 0662057M82 2.2K
R3212 0662057M90 4.7K
R3213 0662057M82 2.2K
R3214 0662057M34 22
R3215 NOTPLACED
Circuit
Ref.
Motorola
Part No.
Description
R3218 NOTPLACED
R3219 0662057M50 100
R3220 0662057M90 4.7K
R3221 0662057M50 100
R3222 NOTPLACED
R3223 NOTPLACED
R3224 0662057M26 10
R3225 0662057M74 1K
R3226 0662057M26 10
R3270 0662057M74 1K
R3271 0662057M42 47
R3272 0662057N15 47K
R3273 0662057N15 47K
R3274 0662057M83 2.4K
R3275 0662057M74 1K
R3276 0662057N30 200K
R3301 NOTPLACED
R3303 0662057N23 100K
R3304 0662057N23 100K
R3305 0662057N19 68K
R3306 0662057M82 2.2K
R3307 0662057N11 33K
R3308 0662057M78 1.5K
R3309 0662057M92 5.6K
R3310 0662057M98 10K
R3311 0662057M26 10
R3312 0662057M38 33
R3313 0662057M34 22
R3314 0662057M26 10
R3315 0662057M62 330
R3316 0662057M66 470
R3317 0662057N23 100K
R3318 0662057M66 470
R3319 NOTPLACED
R3320 NOTPLACED
R3321 0662057M54 150
R3322 0662057M58 220
R3323 0662057M32 18
R3324 0662057M58 220
R3501 0662057M61 300
R3502 0662057M32 18
R3503 0662057M61 300
R3505 0662057M62 330
R3506 0662057B62 3.9
R3507 0662057B62 3.9
R3512 NOTPLACED
R3513 NOTPLACED
Circuit
Ref.
Motorola
Part No.
Description
R3519 0680539Z01 0.1
R3541 0662057N13 39K
R3542 0662057M92 5.6K
R3543 0662057M50 100
R3544 0662057A25 100
R3545 0662057A25 100
R3546 0662057N01 12K
R3547 0662057N11 33K
R3548 0662057N07 22K
R3551 0662057M40 39
R3561 0662057N01 12K
R3562 0662057N11 33K
R3563 0662057N33 270K
R3564 0662057N35 330K
R3565 NOTPLACED
R3566 NOTPLACED
R3569 0662057M92 5.6K
R3570 0662057M98 10K
R3571 0662057A27 120
R3572 0662057A27 120
R3573 0662057A27 120
R3701 0662057M50 100
R3702 NOTPLACED
R3703 0662057M54 150
R3704 0662057M54 150
R3705 0662057N11 33K
R3721 0662057M66 470
R3722 0662057M68 560
R3723 0662057M50 100
R3726 NOTPLACED
R3727 0662057N23 100K
R3741 0662057M50 100
R3751 0662057N30 200K
R3752 0662057N29 180K
R3760 NOTPLACED
R3761 0662057N15 47K
R3762 NOTPLACED
R3763 NOTPLACED
R3801 NOTPLACED
R3802 0662057M50 100
R3803 0662057M58 220
R3804 0662057M98 10K
R3805 0662057N08 24K
R3806 0662057M34 22
R3807 NOTPLACED
R3808 0662057M26 10
R3811 0662057M50 100
Circuit
Ref.
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
