Motorola GP360 Basic User's Guide

2
English
BASIC USER GUIDE
GENERAL INFORMATION
This user guide covers the basic operation of the
GP360 Portable Radio. Please consult your dealer for
further, more detailed information which is contained in
a full feature user guide 6864110B26_.
ATTENTION!
This radio is restricted to occupational use only to satisfy
ICNIRP RF energy exposure requirements. Before using
this product, read the RF energy awareness information
and operating instructions in the Product Safety and RF
Exposure booklet (Motorola Publication part number
6864117B25_) to ensure compliance with RF energy
exposure limits.
OPERATION AND CONTROL FUNCTIONS
Radio Controls
The numbers below refer to the illustrations on the
inside front cover.
1. Rotary Knob
Used as a channel selector and for multi-
function scrolling.
2. On-Off / Volume Knob
Used to turn the radio on or off, and to adjust
the radio’s volume.
3. Side Button 1 (programmable)
Recommended for Monitor/Cancel Button.
4. Push to Talk Button (PTT)
Press and hold down this button to talk, release
it to listen.
5. Side Button 2 (programmable)
6. Side Button 3 (programmable)
7. Top Button (programmable)
Recommended as Emergency button.
8. LED Indicator
Green:
Successful power up.
Green Flashing: Radio scanning.
Red: Radio transmitting.
Red Flashing: Channel busy - when receiving.
Yellow: Radio called.
Yellow Flashing: Radio call reminder alert.
Red Flashing: Low battery warning - when
transmitting.
9. Microphone
10. LCD Display (1 Line)
11. Menu Keys
12. Antenna
13. Accessory Connector
Connects headsets, remote speaker/micro-
phones and other accessories. Replace
attached dust cap when not in use.
Before using this product, read the operating
instructions for safe usage contained in the
Product Safety and RF Exposure booklet
6864117B25_ enclosed with your radio.
!
Caution

Motorola GP360 Specifications

Battery

battery life with standard high capacity NiMH battery low power	11 hours
battery life with standard high capacity NiMH battery high power	8 hours
battery life with ultra high capacity NiMH battery low power	14 hours
battery life with ultra high capacity NiMH battery high power	11 hours
battery life with NiCD battery low power	12 hours
battery life with NiCD battery high power	9 hours
battery life with Li-lon low power	11 hours
battery life with Li-lon high power	8 hours

Operating Environment

operating temperature	-20°C to +55°C
sealing	Withstands rain testing per MIL STD 810 C/D/E and IP54
shock and vibration	Protection via impact resistant housing exceeding MIL STD 810-C/D/E and TIA/EIA 603
dust and humidity	Protection via environment resistant housing exceeding MIL STD 810 C/D/E and TIA/EIA 603

Transmitter Specifications

frequencies full bandsplit VHF	136-174 MHz
frequencies full bandsplit UHF	403-470 MHz
channel spacing	12.5/20/25 kHz
frequency stability	±2.5 ppm
power VHF	1-5W
power UHF	1-4W

Receiver Specifications

frequencies full bandsplit VHF	136-174 MHz
frequencies full bandsplit UHF	403-470 MHz
channel spacing	12.5/20/25 kHz
frequency stability	±2.5 ppm
sensitivity (12 dB SINAD) EIA	0.25 µV typical
sensitivity (20 dB SINAD) EN	0.50 µV typical

Weight and Dimensions

dimensions with standard high capacity NiMH battery	137 x 57.5 x 37.5 mm
dimensions with ultra high capacity NiMH battery	137 x 57.5 x 40.0 mm
dimensions with NiCD battery	137 x 57.5 x 40.0 mm
dimensions with Li-lon battery	137 x 57.5 x 33.0 mm
weight with standard high capacity NiMH battery	428 gm
weight with ultra high capacity NiMH battery	508 gm
weight with NiCD battery	458 gm
weight with Li-lon battery	358 gm
