Motorola L2 Service Manual

6809495A75-O October 14, 2005 33
Level 1 and 2 Service Manual Disassembly
7. Carefully thread the display flex connector through the opening on the chassis
assembly.
8. Lower the display module fully onto the chassis assembly and gently press it
into place.
9. Reassemble the transceiver PC board, antenna, SIM, battery, and battery
cover as described in the procedures.

Motorola L2 Specifications

General

Brand	Motorola
Model	L2
Category	Cell Phone
Language	English
