Motorola L702 Series User Manual

Doc Title : Product Data - User Manual Revision : R.00
Model : Motorola L702 series Page(s) : 13 of 36
This document contains confidential and proprietary information of VTech Telecommunications Ltd
1 SCROLL UP / VOLUME UP
a) In menu mode: Press to scroll up.
b)
In
editing
mode:
Press to move the cursor to the left.
c)
During
a
call:
Press to increase the volume.
d) Calls list / phonebook / redial list entry: Press to scroll up the list.
e) In answering machine mode: Press to increase volume.
2 MENU / SELECT
a) In idle mode: Press to access menu list.
b) In menu / editing mode: Press to confirm and save the settings.
c)
During
a
call:
Press to transfer the call to another handset.
d)
In
call
s
list
entry:
Press to save the entry to the phonebook.
e)
In
phonebook
entry:
Press to go to phonebook editing mode.
3 RIGHT / CALLS LIST
a) In idle mode / during a call: Press to access calls list.
b)
In
editing
mode:
Press to move the cursor to the right.
4 TALK OFF / BACK
a)
In
menu
/
editing
mode:
Press to exit to previous level.
b) In pre-dial mode / phonebook / calls list/redial list entry /answering machine mode:
Press to exit to idle.
c) During ringing: Press to silence the incoming ringer temporarily.
d) During a call: Press to end a call.
5 ALPHANUMERIC KEYPAD
a)
In
idle
/
pre-dial
/
editing
mode
/
during
a
call:
Press to enter characters / numbers.
Press and hold to activate speed dial.
6 #/ PAUSE / ABC / FORMAT
a) In idle /pre-dial / number editing mode / during a call: Press to insert a “#”, press and
hold to insert a pause (P).
b) In name editing mode: Toggle ABC / abc.
c) In calls list entry: Press to toggle Caller ID display format between 7, 8, 10 and 11 digits.
d)
In
Phonebook
list
entry:
If the number is more than 15 digits, press to view the nest
page of remaining digits.
7 INTERCOM
a) In idle mode / during a call: Press to initiate an intercom call.
8 MICROPHONE
9 SPEAKER
a) In idle / pre-dial mode: Press to turn on/off the speakerphone.
b) During a call: Press to toggle between the speakerphone and the earpiece.
c) Calls List/phonebook/redial list entry: Press to make a call with the speakerphone.
d)
During
ringing:
Press to answer a call with the speakerphone.
e)
In
answering
machine
mode:
Press to toggle the message playback via earpiece /
speakerphone
