IN-1
Index
Numerics
162Bug
disk/tape controller data D-1
firmware 3-9
implementation 3-3
network controller data C-1
overview 3-1
stack space 3-4
27C040 EPROM 3-3
53C710 SCSI controller 4-17
82596CA LAN coprocessor 4-16
A
abort process 2-13
ABORT switch 4-20
aborting program execution 2-1
address/data configurations 1-26
addressing modes 1-26
altitude (operating) A-1
ambient air temperature (effect on cooling)
A-2
arbitration priority 4-19
arguments, firmware command 3-5
autoboot process 2-9
autojumpering (VME backplane) 1-25
B
backplane jumpers 1-24
backward compatibility 3-9
battery 4-9
battery precautions 4-10
baud rate, default 2-8
BBRAM (battery-backed-up RAM) and
clock 3-9, 4-11
BG (bus grant) signal 1-24
block diagram, MVME162P4 4-4
board
architecture 4-1
configuration 1-4
connectors 4-19
dimensions A-1
features 4-1
installation 1-23
preparation 1-1
storage, preparation for 4-9
booting the system 2-9, 2-10, 2-11
BREAK key 2-14
break process 2-14
bus grant (BG) signal 1-24
C
cable connections 1-25
cables, I/O ports A-4
cache memory 4-6
chassis grounding A-4
CISC embedded controller(s) D-1
CLUN (controller LUN) C-1, D-1
command identifier, firmware 3-5
command line input, firmware 3-5
commands, firmware
CNFG (Configure Board Information
Block) 3-9
ENV (Set Bug/Operating System
Environment) 3-11
compatibility, backward 3-9
