Getting Started
2.1
Connecting the Power Supply for the Camera
• Insert the DC plug of the power
adapter into the DC socket on the
back of the Camera.
•
Connect the other end of the
power adapter to a suitable
electrical outlet.
•
The Camera turns on and the
power indicator lights up blue.
Note
Only use the supplied power
adapter (DC5V/1000mA).
2.2 Fixing mount to the wall
• Mark the position of the screw holes on the wall.
•
Install wall anchors (if suitable for the wall type) and the wall
mounting screws.
•
Remove the desk stand by loosening the screw on the underside of
the desk stand.
• Fix the camera on the wall mount bracket by fastening the screw.
Screw
Screw
