Motorola PIP11 User Manual

12 Getting to know your baby monitor
2. Getting to know your baby monitor
Overview of your baby unit
Front view Back view
A Night light (amber LED)
B Microphone
C Power button
Press and hold to turn the baby unit on or o.
D Power / Linking LED indicator
Turns on when the parent unit is powered on and linked to the baby unit.
Flashes when the parent and baby units are not linked with each other.
E Speaker
F Temperature sensor
G Power jack
A
B
C
D
E
F
G

Motorola PIP11 Specifications

General

Type	-
Night mode	Yes
Maximum range	300 m
Built-in camera	No
Channels quantity	- channels
Number of lullabies	5
Maximum indoor range	48.7 m
Temperature measurement range	14 - 39 °C
Display type	LCD
Product color	White
Volume control	Buttons
Battery type	AA
Battery capacity	550 mAh
Battery life (max)	10 h
Battery technology	Nickel-Metal Hydride (NiMH)
Receiver power source	AC, Battery
Transmitter power source	Battery
LED indicators	Link, Power

Weight and Dimensions

Receiver weight	344 g
