c. sliding the battery into the charger pocket,
ensuring complete contact between the char-
ger and battery contacts
Figure 1. Battery Charger
SOCKET
(located here)
RAISED RAIL
CHARGING
CONTACTS
POCKET
WARNING
LABEL
LED
