RADIO OVERVIEW
Radio Overview
2
English
OPERATION AND CONTROL FUNCTIONS
Radio Controls
Refer to the illustrations on the previous page.
1. Rotary Knob
Used as a multi-function scroll key and as a
channel selector (Conventional mode).
2. On-Off / Volume Knob
Used to turn the radio on or off, and to adjust
the radio’s volume.
3. Clear Button (Side Button 1)
Used to cancel a call, clear down at the end of
a call or Carrier Monitor (Conventional mode).
4. Push to Talk (PTT) Button
Press and hold down this button to talk, release
it to listen.
5. Side Button 2
Personality button, otherwise programmable.
6. Side Button 3
(programmable)
7. Top Button
(programmable)
Recommended as Emergency button.
8. LED Indicator
Green
: Flashes to indicate NO SERVICE.
Red
: On when radio is transmitting.
Red Flashing
: When transmitting - battery low.
Red Flashing
: When receiving - channel busy
(Conventional Mode).
9. Microphone
10. LCD Screen
11. Menu Keys
12. Keypad
13. Antenna
14. Accessory Connector
Connects headsets, remote speaker/micro-
phones and other accessories. Replace
attached dust cover when not in use.
Programmable Buttons
Several of your radio buttons can be
programmed (by using the Customer
Programming Software — CPS) to activate the
radio features.
The following table shows the features that can
be assigned to the Top button and the Side
Buttons 2 and 3.
#PTX760.book Page 2 Thursday, June 3, 1999 6:16 PM
