RADIO OVERVIEW
English
17
Charging a Standalone Battery
To charge a stand alone Motorola battery,
follow steps 1 to 3 in the previous section and
insert the battery into the tray, with the inside
surface of the battery facing the front of the
charger. Ensure the slots in the battery
correctly engage in the charger (see next
section for battery type details).
Charging a Standard Battery
The drop-in tray charger has a removable
bracket that is adjustable depending on the
type of battery that needs to be charged. The
drop-in tray charger's default position will
charge a standard battery. The following image
shows the orientation of the bracket for each
battery:
Adjustable bracket
with slots on the top
Standard
High and Ultra High Capacity
Adjustable bracket
with slots on the bottom
