10 Mobile Antenna Installation
Figure 9. Coaxial Cable Stripping Dimensions
Figure 10.
Suggested Crimp Area
Base of Pin
Tip of Pin
2 mm
Flared
Braid
Connector
Body
Collar
Ferrule
Cable Inserted into
Connector Body
Crimp Center
Contact after
Inserting Cable
Protruding
Center
Conductor
Collar Slipped
Forward over
Connector Body
Push Ferrule Forward
over Braid. Flange
Butts against Connector
Body. Crimp Ferrule to
Complete Crimp
MAEPF-27622-O
