Motorola TLKR T92 H2O User Manual

English
6
MENU OPTIONS
Selecting the Channel
Your radio has eight channels. The channel is the frequency the
radio uses to transmit.
1. With the radio ON, press Menu button until the channel
number starts to flash.
2. Press or to change the channel. Long press on
these keys allows you to scroll through the channels rapidly
to browse the codes.
3. Press PTT button to exit menu or Menu button to
continue set up.
Selecting the Interference Eliminator Code
Interference Eliminator Codes help minimize interference by
blocking transmissions from unknown sources. Your radio has
121 Interference Eliminator Codes.
To set the code for a channel:
1. Press Menu button twice until the code “9” starts to
flash.
2. Press or to select the code. You can press or hold
to speed up scrolling through the codes.
3. Press the PTT button to exit menu or Menu button to
continue set up.
Setting and Transmitting Call Tones
Your radio can transmit different call tones to other radios in
your group so you can alert them that you want to talk. Your
radio has 20 call tones for you to choose from.
To set a call tone:
1. Press Menu button three times until Call Tone icon
appears. The current call tone setting will flash.
2. Press or to change and listen to the call tone.
Menu Key
Menu Key
Menu Key
Menu Key
Menu Key
Menu Key
Menu Key
Menu Key
Menu Key
Menu Key
Two Way Mode
Channel (1-8)
Sub Code (0-121)
Call Tone (1-20)
Vibrate Alert (On/Off)
Keypad Tones (On/Off)
Talk Confirmation Tones (On/Off)
Dual Watch Channel (1-22)
Dual Watch Interference Eliminator Code
Voice Operated Transmission
(VOX) (Off, L1,L2,L3)

Motorola TLKR T92 H2O Specifications

General

Purpose	-
Maximum range	10000 m
Operating frequency	- MHz
On/off switch	Yes
Product color	Black, Yellow
Transmit power	500 mW
Battery life (max)	16 h
Battery technology	Nickel-Metal Hydride (NiMH)
Quantity	2
Call rings quantity	20

Weight and Dimensions

Weight	233 g
Dimensions (WxDxH)	61 x 38 x 178 mm
