Motorola V3 Instruction Manual

DR
AFT
13
Getting Started
Tip: The USB adapter makes it easier for you to use your
phone with an attached battery charger or phone
accessory.
Note: You can safely leave the travel charger connected to
the phone after charging is complete. This will
not damage
the battery.
Action
1
Insert the travel
charger plug into
the detachable
USB adapter as
shown.
2 Insert the USB
adapter plug into
the USB connector
port on your
phone.
3 Plug the other end of the travel charger into the
appropriate electrical outlet.
Note: It may take up to 10 seconds for your
phone to provide a visible or audible indication
that the battery is charging.
4 When your phone indicates Charge Complete ,
remove the travel charger.

Motorola V3 Specifications

General

FM radio	No
Ringer type	Polyphonic
Polyphonic rings quantity	40
Rear camera resolution	640 x 480 pixels
Interface	CE Bus, USB / Bluetooth
Networking type	GSM
Playback formats	MIDI, MP3
Operating frequency	GSM 850 / GSM 900 / GSM 1800 / GSM 1900 MHz
Internal memory	5.5 MB
Compatible memory cards	Not supported
Type	-
Product color	Aluminum
Form factor	Flip
Personal info management (PIM)	Games, Calendar, To-do list
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Battery type	Li-Ion
Talk time (2G)	3 h
Battery capacity	680 mAh
Standby time (2G)	200 h
Display type	TFT
Display diagonal	2.2 \
External display	CSTN
Display resolution	176 x 220 pixels
Display number of colors	65536 colors
External display resolution	96 x 80 pixels
WAP	2.0
Data network	GPRS
SIM card type	MiniSIM
SIM card capability	Single SIM
USB connector type	Mini-USB
Video compression formats	MPEG4

Weight and Dimensions

Depth	13.9 mm
Width	53 mm
Height	98 mm
Weight	95 g
