5 Operation
20 Rev. 12/2019
5.3.2 Voltage Display
The voltage display of the SparkView high voltage indicator shows the currently measured
voltage. With activated maximum value indication (see section Preferences on page 21), maxi-
mum values are kept for 0.5 seconds in the voltage display.
Risk of destruction!
Excess voltage may destroy or damage the SparkView high voltage indica-
tor. Stop the measurement immediately if continuously values above 25 kV
(set measuring range up to 25 kV) or above 50 kV (set measuring range up
to 50 kV) are measured.
If values above the set permissible measuring range are measured, all LEDs of the voltage dis-
play light up red. In such a case, stop measuring immediately, as inadmissible measured values
can destroy or damage the SparkView.
5.3.3 Status Display
The status display of the SparkView high voltage indicator lights up as soon as the device is
switched on and it goes out when switched off. The different states of the status display have
the following meaning:
Status display Meaning
Green light The batteries are fully charged.
ellow light The batteries have a medium charge level.
Red light The batteries are weak.
Flashes red The batteries are almost flat and should be
replaced (see section Changing the Battery on
page 30).
Flashes red once and goes out The device has been switched off manually.
Flashes red three times and goes out The device has switched off automatically after
5 minutes of not being used.
Flashes red five times and goes out The device has switched off due to flat batter-
ies. The batteries must be replaced (see sec-
tion Changing the Battery on page 30).
Flashes red more than five times There is a fault.
