MouKey MA20-1 - Speaker Component Identification; Front View Components; Side View Components; Rear View Components

MADE IN C HINA
WARNI NG
Elect ric Sho ck Haza rd,
Non Pro fessi onals ,
Do Not Op en!
12
3
1:L 2:R 3:GND
A
B
C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
3
A: Front view
B: Side view
C: Rear view
1: Silk film tweeter x1
2: Midrange 2 inch x1
3: Vent
4: Remote control receiver light
5: Bass 4 inch x1
6: Treble adjustment knob
7: Bass adjustment knob
8: Volume adjustment knob
9: Audio source status indicator
(red AUX input, blue
is Bluetooth status)
10: AUX RCA input interface
11: AUX 3.5mm input interface
12: Speaker connection port
13: Monitor output interface
14: Power switch button
15: Power cord
Speaker
