Adjusting the Spring Arm Tension
“ + ” : Increase Tension
If the arm raises on its own then turn the adjustment bolt toward the “ - ” symbol to decrease
tension until the arm stops at the desired position.
If the arm lowers on its own then turn the adjustment bolt toward the “ + ” symbol to increase
tension until the arm stops at the desired position.
“ - ” : Reduce Tension
90°
Release
Remove the Crossbar Latch
Keep the mount arm in this 90° angle when adjusting the spring
tension (detailed below.)
Adjust the tension of the spring arm until it stops freely at all
lowered positions.
Attention:
To Next Page
