Parts of the Buggy Frame
Note: Diagram is urban jungle model *Points to lubricate periodically
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1. Handlebar
2. Handle Adjuster
3.Crossbracebar
4.Sidetube
5.Brakelever
6. Brake cog
7.BrakeCam*
8.Rearaxle
9.Rearwheel
10.Quickreleaseclip
11. Base tube
12. Sunhood lugs
13.Downtube
14.Hingejoint
15.Slidinglock*
16. Secondary lock
17.Riserplate
18.Footrest
19.Swivelknob
20.Frontwheelswivel*
21.Frontwheel
