Mountain Buggy swift - Wheel Assembly and Adjustment; Front Wheel Assembly and Removal; Rear Wheel Assembly and Removal

4
Front Wheel Assembly
1. Holding both knobs at the same time, unscrew and
pull out the front axle.
2. Insert the front wheel.
3. Re-inserttheaxleandtightenbothknobsbyhand
to secure wheel in place.
To remove
Repeataboveinreverse.
Tracking device (terrain only)
1. Swivel front wheel straight ahead in the lock
forward position.
2. Loosen knobs on both sides of front wheel.
3. Movetrackingadjustorforwardorbackwardto
adjust wheel position, so it runs in a straight line.
4. Tightenknobstosecurethefrontwheelinplace.
Rear Wheel Assembly
1. swift,urbanjungleandterrainwithpush-inaxle:
 • Pushforwardonthegreyaxlereleasetaband
push the axles out slightly and release the tab.
 • Pushtheaxleoutfurtheruntilyouhearaclick.
2. all buggies:
 • Slidewheels(withbrakecogfacinginwards)
onto the axles.
 • Pusheachwheelonuntilitclicksintoplace.
Pull on the wheel to ensure it is secure.
To remove
Depress quick release clip and slide wheel o axles. swift,
urban jungle and terrain axles can be pushed in to reduce
thetotalfoldedsize.Pushtheaxlereleasetabandpushthe
axles in until they click into place.
Wheel Assembly
axle
tracking
adjustor
