Mountain Top Wildtrak - The Roll Cover Does Not Open or Close Freely; The Roll Cover Opens When Driving on Uneven Terrain; The Lock System Does Not Work Correctly; Jams; Objects Stored in Bed Becomes Wet; Dirty

01/30
Mountain Top
®
Roll Troubleshooting manual (Wildtrak)Contents
THE ROLL COVER DOES NOT OPEN OR CLOSE FREELY
1.A The fl ockinglists are dry / dirty
1.B The side rails have not been aligned correctly / have shifted
1.C Side rail brackets have not been tightened correctly / have loosened
1.D The main spring has not been tightened correctly / has lost tension
p. 02
p. 03
p. 06
p. 07
1
THE ROLL COVER OPENS WHEN DRIVING ON UNEVEN TERRAIN
2.A The side rails have not been installed correctly / have shifted
2.B The roll cover has not been installed correctly / locking holes do not align
2.C The bolts holding the side rails have loosened
2.D The rear profi le is of and older type
p. 08
p. 10
p. 13
p. 15
THE LOCK SYSTEM DOES NOT WORK CORRECTLY / JAMS
3.A The roll cover cannot be unlocked with the key
3.B The roll cover does not open when the lock button is pressed down
3.C The lock button is jammed / hard to press down
3.D The lock release is jammed in its outer position
3.E The roll cover does not lock in 1/3, 2/3, or closed positions
3.F Replace the rear profi le
p. 16
p. 17
p. 18
p. 23
p. 24
p. 25
2
3
OBJECTS STORED IN THE BED BECOMES WET / DIRTY
4.A Water / dirt ingress occurs multiple places (EB3B specifi c)
4.B Water / dirt ingress occurs multiple places (A66+AB39 specifi c)
p. 26
p. 28
4
