13
EN
CONTROLS AND INSTRUMENTS
«START» connects the starter motor.
If you release the key on «START», it will automatically return to «ON».
4.4 PARKING BRAKE
This brake stops the machine from moving when it has been parked. There are two
positions:
«A» = Brake off
«B» = Brake on
– The brake is applied by pressing the pedal right down (4.21 or 4.31) and moving the
lever to position «B». When you take your foot off the pedal it will be blocked by the
lever in the lowered position.
–To disengage the parking brake, press the pedal (4.21 or 4.31). The lever will return
to position «A».
4.5 HEADLIGHT SWITCH ( if fitted)
For turning on the headlights when the key (4.3) is in the «ON» position.
4.6 PILOT LAMP AND SOUND WARNINGS
This lamp comes on when the key (6) is in the «ON» position and stays on while the
machine is running.
– When it flashes, it means that the engine is not ready to start (
☛ 5.2).
– The sound warning signals that the grass-catcher is full (
☛ 5.4.6).
4.7 BLADE ENGAGEMENT AND BRAKE CONTROL
The mushroom switch allows you to engage the blades using the electromagnetic
clutch:
«A» Pressed = Blades disengaged
«B» Pulled = Blades engaged
– If you engage the blades without taking the necessary safety precautions, the
engine shuts down and cannot be restarted (
☛ 5.2).
– Blade disengagement (Pos. «A»), simultaneously activates a brake which stops their
rotation in a few seconds.
➤
