Mountz MDC Series - SD Memory Card

mountztorque.com - 1080 N 11
th
St, San Jose CA 95112 - 408.292.2214
33
System creates the folders of YEAR, MONTH automatically. And it creates one file in CSV
format with the file name of DATE.
SD CARD > 2017 (folder) > 07 (folder) > 21 (file) ….. File name : 21.csv
The real time fastening data in Monitoring menu are stored together with the system clock time
of the controller.
Clock time, Fastening time, Preset#, Target torque, Converted torque, Speed, A1, A2, A3 angles, Count no.
Error code, Forward/Reverse, Status(OK), Snug angle
SD Memory card
- drvstate.txt
HISTORY  folder
YEAR  folder / one folder per year
MONTH  folder / one folder per month
- Date.csv  monitoring data file / one file per one day
** The last scanning data is recorded together with every fastening dat
