Movex FB Series - Technical Description; General; Classification; Technical Specification

8
Technical specificaon
Model Output Voltage Frequency Current Motor speed Cos Weight *Contactor *Protecve
with overcurrent motor
protecon switch
FB 076-1 0.7 hp 115 V 1N~ 60 Hz 7.2 A 3340 rpm 0.93 49 lb SKO 100-7/115 SMB 100
FB 106-1 1.0 hp 115 V 1N~ 60 Hz 10 A 3360 rpm 0.94 66 lb SKO 130-7 /115 SMB 140
FB 206-1 2.0 hp 115 V 1N~ 60 Hz 20 A 3360 rpm 0.99 101lb SKO 240-15/115 SMB 250
FB 076-3 0.7 hp 208 V 3~ 60 Hz 2.45 A 3440 rpm 0.81 48 lb SKO 40-5 /115 SMB 40
FB 106-3 1.0 hp 208 V 3~ 60 Hz 4.10 A 3360 rpm 0.66 66 lb SKO 60-5/115 SMB 63
FB 206-3 2.0 hp 208 V 3~ 60 Hz 6.20 A 3470 rpm 0.79 101lb SKO 80-5/115 SMB 100
FB 406-3 4.0 hp 208 V 3~ 60 Hz 11.7 A 3350 rpm 0.81 150lb SKO 180-10/115 SMB 140
FB 706-3 7.0hp 208 V 3~ 60 Hz 19.4 A 3535 rpm 0.88 227lb SKO 240-20/115 SMB 250
FB 1506-3 15 hp 208 V 3~ 60 Hz 38.9 A 3550 rpm 0.86 377lb
FB 076-3 0.7 hp 230 V 3~ 60 Hz 2.20 A 3440 rpm 0.81 49lb SKO 40-5/115 SMB 40
FB 106-3 1.0 hp 230 V 3~ 60 Hz 3.70 A 3360 rpm 0.66 66lb SKO 60-5/115 SMB 63
FB 206-3 2.0 hp 230 V 3~ 60 Hz 5.60 A 3470 rpm 0.79 101lb SKO 80-5/115 SMB 100
FB 406-3 4.0 hp 230 V 3~ 60 Hz 10.6 A 3530 rpm 0.81 150lb SKO 130-10/115 SMB 140
FB 706-3 7.0 hp 230 V 3~ 60 Hz 17.6 A 3535 rpm 0.88 227lb SKO 240-15/115 SMB 230
FB 1506-3 15 hp 230 V 3~ 60 Hz 35.2 A 3550 rpm 0.86 377lb
FB 076-3 0.7 hp 460 V 3~ 60 Hz 1.10 A 3440 rpm 0.81 49lb SKO 16-5/115 SMB 16
FB 106-3 1.0 hp 460 V 3~ 60 Hz 1.85 A 3360 rpm 0.66 66lb SKO 25-5/115 SMB 25
FB 206-3 2.0 hp 460 V 3~ 60 Hz 2.80 A 3470 rpm 0.79 101lb SKO 40-5/115 SMB 40
FB 406-3 4.0 hp 460 V 3~ 60 Hz 5.30 A 3350 rpm 0.81 150lb SKO 80-5/115 SMB 100
FB 706-3 7.0 hp 460 V 3~ 60 Hz 8.80 A 3535 rpm 0.88 227lb SKO 130-7/115 SMB 140
FB 1506-3 15 hp 460 V 3~ 60 Hz 17.6 A 3550 rpm 0.86 377lb SKO 240-15/115 SMB 230
Technical descripon
General
The Movex FB fan series is delivered in a robust
box or on a wooden pallet with the required
packaging material.
A rang plate is affixed to the motor.
The working temperature through the fan is
max. 175°F and the ambient temperature
between -14° to +104°F. Atmospheric humidity
must not exceed 90%.
The fan's motor generates heat and is
fied with a cooling fan. The inlet to
the cooling fan is at the rear of the motor.
Do not block the inlet.
Enclosure class: IP 55
Usage type:
Conformity:
Movex FB fans conform to demands in accordance
*Contains UL listed components
