MOVINCOOL 24HFU / 24HFU-1 OPERATION PAGE 5
INVENTORY & ASSEMBLY
Assembly
CAUTION: Before assembling
make sure the unit is on a flat,
level surface and the casters are
in the “LOCKED” position. (Both
the 24HFU and 24HFU-1
MovinCool units have locking
swivel casters in the front only.)
Install each cool air outlet using 4 screws each as shown.
NOTE: Do not overtighten the screws when installing the cool air
outlets. This could damage the base on the cool air outlet assembly.
LOCKED
UNLOCKED
SCREW (4)
COOL AIR OUTLET (2)
SCREW (4)
