Mowox PM5160SEHW User Manual

8
Fig.1D PM 5157 SEHW-B(DYM1560EDQ)
4. TECHNICAL DATA
Model
PM 4645SEHW
(DYM1676CD-3)
PM5160SEHW
(DYM1678D-3)
PM4335SE
(DYM162002)
PM5157SEHW-B
(DYM1560EDQ)
Engine type DYM1P64FE DYM1P70FE DYM1P56FE B&S 575IS
Engine Displacement 135 cm
3
173cm
3
98.5cm
3
150cm
3
Nominal Power 2.4Kw 3.6kw 1.9kW 2.2kW
Blade Width 460mm 510mm 430mm 510mm
Rated Speed 2800/min 2800/min 2900/min 2800/min
Fuel Tank Capacity
1.2L
2.0L
0.8L
0.8L
Grass catcher capacity
60L
60L
50L
60L
Net Weight
39kg
41.7kg
33.7kg
33.7kg
Height adjustment
25-75mm 7adjustment
25-75mm 10adjustment
Charger model HYCH0131380500G CU25-1124200 or IS12C
Charger technical data Input:AC100-240V,50-60Hz ， 0.32A
Output voltage
13.8Vd.c. , 0.5A
Input : 100-240V~，
50/60Hz, 0.8A
Output : 12.45V d.c.,
2.0A
Model
PM 4645SEHW
(DYM1676CD-3)
PM5160SEHW
(DYM1678D-3)
PM4335SE
(DYM162002)
PM5157SEHW-B
(DYM1560EDQ)
Guaranteed Sound pressure level
at the operator’s position
(According to EN ISO 5395-1 Annex
F & EN ISO 5395-2, EN ISO 4871)
82dB(A)
(K=3 dB(A))
84.9dB(A)
(K=3 dB(A))
87.3dB(A)
(K=3 dB(A))
88.0dB(A)
(K=3 dB(A))
Measured sound power level
Guaranteed Sound Power level
(According to 2000/14/EC)
92.0dB(A)
K=2.59dB(A)
96 dB(A)
95.0dB(A)
K=2.88B(A)
98 dB(A)
94.95dB(A)
K=0.99dB(A)
96 dB(A)
95.1dB(A)
K=1.94dB(A)
98 dB(A)
Vibration
(According to EN ISO 5395-1 Annex
G & EN ISO 5395-2)
3.099m/s²
K=1.5 m/s²
3.437m/s² ,K=
1.5 m/s²
7.291m/s²
K=1.5 m/s²
5.84m/s² K=1.5
m/s²
