Mowox RM 600 Li BT - User Manual

Questions and Answers

L
Larry BurnsSep 3, 2025
What to do if my Mowox RM 600 Li BT screen is off?
- T
  Tracy HendersonSep 3, 2025
  If the screen on your Mowox Lawn Mower is off, try pressing the power key on the keyboard for 3 seconds to turn the LCD screen on. Also, ensure the main power switch is set to “ON”. If you are using the mower for the first time, the battery may not be fully charged, so place it in the charging station. You can also try hitting the power key on the control panel, then input your PIN to start the mower. If the screen remains off, place the mower in the charging station, ensuring the main switch is “ON” to allow charging.
K
kathryngrossSep 18, 2025
What to do if my Mowox Lawn Mower battery temperature is abnormal?
- V
  Victoria LeeSep 18, 2025
  If your Mowox Lawn Mower returns to the station during working time or the battery won't charge, it might be due to abnormal battery temperature. In summer, set the working time for early morning to avoid the heat. After cooling to the range (charge: 0-45° C; discharge: 0-90° C), it will restore automatically. In winter, move the robot to a warm area or a customer service for winter service.
C
Cindy RogersSep 16, 2025
What to do if my Mowox Lawn Mower behaves abnormally around islands (flower beds, pool, etc.)?
- J
  Jasmin SmithSep 16, 2025
  If your Mowox Lawn Mower behaves abnormally around islands, relocate the boundary wire.
B
burtonteresaSep 14, 2025
What to do if my Mowox RM 600 Li BT does not boot?
- J
  Jason SanchezSep 14, 2025
  If your Mowox Lawn Mower does not boot, remove any metal parts if necessary and take the appliance to a service dealer.
J
Jeremy SmithSep 12, 2025
What to do if my Mowox RM 600 Li BT Lawn Mower operates during rain?
- H
  Heather KingSep 13, 2025
  If your Mowox Lawn Mower operates during rain, clean the rain sensor with a cloth soaked in a detergent solution.
F
fgarciaSep 12, 2025
Why does my Mowox RM 600 Li BT circle around along the boundary wire?
- R
  Rebecca CrawfordSep 12, 2025
  If your Mowox Lawn Mower circles along the boundary wire, check for any high-power cables near or underneath the boundary wire and adjust the wire's position accordingly.
J
Janice MccormickSep 9, 2025
What to do if my Mowox RM 600 Li BT Lawn Mower battery cannot be charged?
- C
  Catherine CastroSep 9, 2025
  If the battery of your Mowox Lawn Mower cannot be charged, verify the power source is working correctly and clean the charging pins if necessary. If the problem persists, consider replacing the battery.
E
emily94Sep 7, 2025
Why doesn't my Mowox RM 600 Li BT enter the charging station?
- B
  Brent SmithSep 7, 2025
  If your Mowox Lawn Mower cannot enter the charging station, ensure the LED indicator on the charging station displays a constant green light. Also, verify that the boundary wire under and in front of the charger is correctly aligned, the charging station is positioned correctly, and the charging station is level.
R
Richard CollinsSep 5, 2025
What to do if my Mowox RM 600 Li BT Lawn Mower robotic mower stopped in the working area because it was lifted?
- A
  angela79Sep 5, 2025
  If your Mowox Lawn Mower stops because it was lifted, check for obstacles lower than 100 mm in the working area. If there are any, remove them or change the boundary wire layout to exclude those areas.
S
Sean AllenAug 20, 2025
What to do if my Mowox RM 600 Li BT stopped in the working area?
- S
  stephen18Aug 20, 2025
  If your Mowox Lawn Mower stops in the working area, several factors could be the cause. It might be trapped by an obstacle or jammed between trees or bushes. Remove any obstacles or adjust the boundary wire layout to avoid the area. Also, check if the grass is too tall, blocking the mower's movement; if so, cut the grass to less than 60 mm. Restart the mower or return it to the charging station. If the issue persists, ensure the boundary wire is correctly laid, especially in narrow corners or around fences.

Summary

1. Safety Instruction

1.1 Safe Operating Practice

Guidelines for safe operation, training, preparation, and use of the mower.

1.2 Robotic Mower Safety Features

Anti-theft and Disabling Device

Security feature requiring a PIN code to prevent unauthorized use.

Lift and Tilt Sensors

Stops blades when mower is lifted or tilted to prevent injury.

Obstruction and Emergency Stop

Describes obstacle detection and emergency stop button functionality.

1.3 Safety Symbols

Safety Switch and Base Station

Explains safety switch operation and base station dependency.

2. Technical Data

4. Basic Operating Principles

4.1 Random Operation

4.2 Obstacle Recognition

4.5 Cutting Height Adjustment

How to adjust the cutting height of the mower between 20 mm and 60 mm.

5. Installation Guide

5.1 Introduction and Preparation

Steps for planning the installation and preparing necessary tools.

5.2 Perimeter Islands

How to use boundary wire to create islands around obstacles like flower beds.

Boundary Wire Crossing Rules

5.3 Boundary Wire Installation

Soil Installation and Edge Distance

Details on digging the boundary wire into the soil and its distance from edges.

Handling Obstacles >100 mm

How to handle fixed obstacles larger than 100 mm using crash sensors.

Slope Handling

Information on handling slopes and their maximum gradient (up to 35%).

Boundary Wire on Slopes

Specific rules for placing boundary wire on slopes to prevent slipping.

5.4 Charging Station Location

Preparing Wire for Station

Steps to prepare the boundary wire for connection to the charging station.

Connecting Station to Wire & Charger

How to connect the boundary wire and power charger to the charging station.

5.5 Turn On and Test Installation

Stopping Mower Operation

How to stop the mower using the red STOP button during operation.

5.6 Secure the Charging Base

6. Programming

6.1 Control Panel Overview

Key Control Panel Options

Explains the function of each button on the control panel for navigation and operation.

6.2 Main Operation Menu

6.4 Settings Menu

Set Date and Time

Secondary Mowing Areas

Set Cutting Weekday and Time

6.5 Cutting and Heading Home

6.7 Change PIN Code

6.8 PIN Forgotten Procedure

6.9 Firmware Update Options

Update via Bluetooth

Update via USB Stick

7. Maintenance Guide

7.1 Battery Life and Care

7.2 Winter Storage

7.3 Cleaning and Maintenance

Cleaning the Mower Body

Cleaning the Underside and Contacts

7.4 Blade Maintenance

Blade Replacement Procedure

7.5 Battery Replacement

8. Troubleshooting Guide

Charging Station Troubleshooting

Solutions for common charging station issues based on LED indicators.

Robotic Mower Troubleshooting

Table of common mower problems, possible reasons, and recommended actions.

Mower Trapped or Lifted

Mower Stopped in Tall Grass or Motor Fault

Mower Stopped, Screen Off, or Battery Low

Boundary Signal Errors

Battery Temperature and Charging Issues

PCB Over-temperature and Mainboard Errors

Battery Charge and Boot Failures

Screen Off and Charging Station Entry Issues

Boundary Wire Interference and Obstacles

Abnormal Behavior and Noise Issues

Mowox RM 600 Li BT Specifications

General

Type	Robotic Lawn Mower
Battery	Lithium-Ion
Battery Voltage	20 V
Battery Capacity	2 Ah
Cutting Width	18 cm
Max Working Area	600 m²
Cutting Height	20-60 mm
Bluetooth	Yes
Mulching Function	Yes
Runtime	60 minutes
Blade Type	3 floating blades
Charging Time	80 minutes
Cutting Height Adjustment	Central adjustment
