- 15 -
100M
(TP)
GREEN
TP port’s 100 Mbps link is active.
Data is being transmitted at 100 Mbps.
TP Port’s 100 Mbps link is inactive.
100M
(FX)
GREEN
FX port’s 100 Mbps is active.
Data is being transmitted at 100 Mbps.
FX port’s 100 Mbps is inactive.
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect the
EDS-405A/408A’s 10/100BaseTX ports to any kind of Ethernet device,
without needing to pay attention to the type of Ethernet cable being used
for the connection. This means that you can use either a straight-through
cable or cross-over cable to connect the EDS-405A/408A to Ethernet
devices.
Specifications
Standards IEEE802.3, 802.3u, 802.3x, 802.1D, 802.1Q,
IGMP V1/V2 device, GMRP, GVRP, SNMPv1/v2c/v3,
DHCP Server/Client, TFTP, SNTP, SMTP, RARP,
RMON, HTTP, Telnet, Syslog, DHCP Option
66/67/82, BootP, LLDP, Modbus TCP, IPv6
MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, RMON
MIB Group 1, 2, 3, 9, Bridge MIB, RSTP MIB
Forwarding and
Filtering Rate
IEEE802.3x flow control, back pressure flow control
10/100BaseT(X) auto negotiation speed, F/H duplex
mode, and auto MDI/MDI-X connection
100BaseFX ports (SC/ST connector)
LED Indicators PWR1, PWR2, FAULT, 10/100M (TP port),
100M (Fiber Port), CPLR/TAIL and MSTR/HEAD
One relay output with current carrying capacity of 1A
@ 24 VDC
Master, Coupler, Turbo Ring, Reserve
5 km
a
, 4 km
b
40 km
c
a. when using [50/125 μm, 800 MHz*km] cable
b. when using [62.5/125 μm, 500 MHz*km] cable
c. when using [9/125 μm, 3.5 PS/(nm*km)] cable
