Moxa Technologies EtherDevice EDS-G205A-4PoE-1GSFP Hardware Installation Guide

- 2 -
Overview
The EDS-G205A-4PoE series industrial Ethernet switches are rugged
entry-level industrial 5-port gigabit PoE switches that support IEEE 802.3,
IEEE 802.3u, IEEE 802.3x with 10/100/1000M, full/half-duplex,
MDI/MDIX auto-sensing, and IEEE 802.3af/IEEE 802.3at PoE standards.
The EDS-G205A-4PoE series provides 24/48 VDC redundant power inputs
that can be connected simultaneously to a live DC power source. The
switches are available with a standard operating temperature range from
0 to 60°C, or with a wide operating temperature range from -40 to 75°C,
and their IP30 metal housing makes them rugged enough for any harsh
industrial environment.
To provide greater versatility for use with applications from different
industries, the EDS-G205A-4PoE switches also allow users to enable or
disable broadcast storm protection with DIP switches on the outer panel.
The EDS-G205A-4PoE switches can be easily installed on a DIN-Rail or in
distribution boxes. The DIN-Rail mounting capability and IP30 metal
housing with LED indicators make the plug-and-play EDS-G205A-4PoE
switches reliable and easy to use.
NOTE
Throughout this Hardware Installation Guide, we use EDS as an
abbr
eviation for Moxa EtherDevice Switch:
EDS = Moxa EtherDevice Switch
Package Checklist
Your EDS is shipped with the following items. If any of these items is
missing or damaged, please contact your customer service
representative for assistance.
• Moxa EtherDevice™ Switch
• Hardware Installation Guide
• Moxa Product Warranty booklet
Features
High-watt Power-over-Ethernet
• Up to 30 watts output per PoE port (IEEE 802.3at)
• Short circuit and over current protection
• Auto detection for IEEE 802.3af and IEEE 802.3at
High Performance Network Switching Technology
• 10/100Base-T(X), 1000Base-T and 1000Base-X (SFP)
• 10/100/1000M, Full/Half-Duplex, MDI/MDIX auto-sensing
• IEEE 802.3/802.3u/802.3x
• Store and Forward switching process type,8K MAC address entries
• 9.6K jumbo frame
Rugged Design
• Redundant dual 24/48 VDC power inputs
• Operating temperature range from 0 to 60°C, or extended operating
temperature of -40 to 75°C for (T) models.
• IP30 metal housing
• DIN-rail or panel mounting ability
