Moxa Technologies OnCell G3100 Quick Installation Guide

- 7 -
Cellular Interface (for OnCell G3110-HSPA & G3150-HSPA)
Data Rate
UMTS (DL: 384 Kbps, UL: 384 Kbps)
HSPA (DL: 14.4 Mbps, UL: 5.67 Mbps)
Standard Compliance
GSM/GPRS/EDGE/UMTS/HSPA
Band Selection
Five band 800/850/AWS/1900/2100 MHz
Quad-band 850/900/1800/1900 MHz
Tx Power
1 watt GSM1800,
2 watt GSM900,
0.25 watt UMTS/HSPA
0.5 watt EDGE900, 0.4 watt EDGE1800
GPRS Multi-slot class
Class 12
GPRS Terminal Device
Class B
GPRS Coding Schemes
CS1 to CS4
SIM Control
3V
Serial Interface
No. of Ports
1
Serial Standards
OnCell G3100:
OnCell G3150:
RS-232 (DB9 male connector)
RS-232 (DB9 male connector),
RS-422/485 (5-pin terminal block connector)
Serial Communication Parameters
Parity
None, Even, Odd, Space, Mark
Data Bits
5, 6, 7, 8
Stop Bit(s)
1, 1.5, 2 (when parity = None)
Flow Control
RTS/CTS, XON/XOFF
Speed
50 bps to 921.6 Kbps
I/O Interface
Alarm Contact
1 relay output with current carrying capacity of
1 A @ 24 VDC
Digital Input 2 inputs electrically isolated from the
electronics
On: +13 to +30 V for state "1"
Off: +3 to -30V for state "0"
Power Requirements
Input Voltage
12 to 48 VDC
Data Link
400 mA (idle) to 900 mA (peak) @ 12 V
Environmental Limits
Operating temperature
Standard:
Wide Temperature:
-30 to 55°C (-22 to 131°F), 5 to 95% RH
-30 to 70°C (-22 to 158°F), 5 to 95% RH
Storage temperature
-40 to 75°C (-40 to 167°F)
Regulatory Approvals
EMC
CE Class A , FCC Class A, UL
Warranty
Warranty Period
5 years
