Section 5 Installation
4. Ensure the power entry switch is “OFF”.
5. Firmly insert the power cord into the outlet on the control unit (fig. 6).
6. Insert the other end of the power cord into an equivalent grounded power
receptacle.
7. Press the power entry switch “ON” and refer to Manual Setup (Section 6).
Note: Check to make sure all hose connections are secure before turning on.
Manual Setup
1. Press the “On/Off” button on the keypad to the “On” position and allow the mattress
to FULLY inflate before making any adjustments or placing the patient on
the
mattress.
On
Off
Figure 5
Section 6 Manual Setup
SelectAir,
SelectAir Max,
HybridSelect
Models
Figure 8
ON/OFF
BariSelect
Models only
Figure 6
Figure 7
Power Entry
Switch
Fuse
Compartment
Power Entry
Receptacle
15 feet (4.6 meters)
11
