Technical manual: CoolGen 4
Copyright: MOZELT GmbH & Co. KG, D-47269 Duisburg Edition: August 2014 Rev.: 00
Page 22
English
4.5 Assembly Plan Power Generator
7
8
1
2
3
4a
5
6
7
8
9
Power generator CoolGen 4
MFD display
Operang pushbuon on the operang lever
Variant A switch line
Control line
Magnet line 230 volt
Plug-and-socket device
Magnet connecon line
Liing magnet
The essenal components are:
3
2
1
4a
4b
5
6
7
9
4b Variant B switch line
Aer the start/stop command has been given LEDs 3 & 4 ash
Anzeige: - LED 3 (red, ashing), „Power o“
- LED 4 (red, ashing), „Line open“
Possible cause: Due to speed uctuaons, the internal intermediate
circuit voltage rises above the allowable value.
Note : The power generator is to be immediately shut down
unl the fault has been corrected.
Contact the MOZELT Service Department
immediately. The fault indicaon can only be
cancelled by shutdown of the power generator.
1
2
3
4
5
Fig.: 30 | MFD signals increased
intermediate circuit voltage
Fig.: 31 | General view arrangement power supply system CG 4
