MOZELT GmbH & Co. KG
Load liing magnet devices
Technical manual: CoolGen 4
Copyright: MOZELT GmbH & Co. KG, D-47269 Duisburg Edition: August 2014 Rev.: 00
Page 4
English
Table of contents
1. Technical descripon 5
1.1 General informaon 5
1.2 Range of Applicaon 5
1.3 Descripon 5
1.4 Funcon mode 5
1.5 Protecon Concept, Behaviour in the Case of Faults 6
1.6 Safety regulaons magnet operaon 6
2. Technical Data 7
2.1 Performance Data 7
2.2 Accessories 7
2.2.1 MFD display 7
2.3 Generator Drives 8
2.3.1 Belt Drives 8
2.3.2 Hydraulic Drives 8
3. Assembling 9
3.1 Assembling instrucons 9
3.2 Installaon of „BELL CLUTCH“ Coupling 9
3.3 EMC Notes Electromagnec Compability 10
3.3.1 Interference Immunity 10
3.3.2 Interference Radiaon 10
3.4 Magnet Connecon 10
3.5 LED Funcons 10
3.6 Control cable 11
3.7 Terminal Box 11
3.8 Terminal Block 12
3.8.1 Start command via switch line on the MFD display 12
3.8.2 Start Command via Terminal Block 12
3.9 USB Connecon 12
3.10 Cable Allocaon 230 Volt 13
3.11 Dimensional Drawings Power Generator 14
4. Commissioning 15
4.1 Safety Notes 15
4.2 Operang instrucons 16
4.3 Operaonal indicators MFD 17
4.4 Fault indicators MFD 19
4.5 Assembly Plan Power Generator 22
4.6 Mechanical Speed Measurement 23
5. Shutdown 23
