1. Espresso machine housing
2. Control panel
a. Single “Espresso” coffee selection
button with control light
b. Double “Espresso” coffee selection
button with control light
c. Small “Cappuccino” coffee selection
button with control light
d. Large “Cappuccino” coffee selec-
tion button with control light
e. Small “Latte” coffee selection but-
ton with control light
f. Large “Latte” coffee selection but-
ton with control light
3. Power switch
4. Place for storing the portafilter and
filter
5. Portafilter and filter mounting socket
6. Sliding stand for a small cup/cups
7. Drip tray mounting space
8. Drip tray
9. Drip tray grate
10. Portafilter for the filter basket
11. Filter lock lever
12. Portafilter handle
13. Coffee filter
a. small coffee filter
b. large coffee filter
14. Water tank mounting socket
15. 1.2L water tank
16. Water valve
17. Water tank cover
18. Milk container installation place
19. 0.7L milk container
20. Milk container cover
21. Milk suction hose
22. Milk/steam dispensing nozzle
23. Milk dispensing knob
24. Steam wand lever
25. Measure – kneader
26. Steam connector
27. Cup heater
FUNCTIONS OF THE ESPRESSO MACHINE, QUALITY OF COFFEE BREW AND STARTING
PROCEDURE
Selected button on the control panel Single press Double press Press and hold for 3 seconds
Espresso
Small
(2a)
40 ml Not active 20-70 ml
(Setting quantity))
Large
(2b)
80 ml 120 ml 40-150 ml
(Setting quantity)
Cappuccino
Large
(2c)
170 ml Not active 5-40 seconds
(Setting steaming time)
Large
(2d)
280 ml 70 seconds (steaming
without brewing coffee)
5-70 seconds
(Setting steaming time)
Latte
Large
(2e)
350 ml Not active 5-70 seconds
(Setting steaming time)
Large
(2f)
450 ml Espresso machine self-
cleaning function
5-90 seconds
(Setting steaming time)
CAUTION:
– depending on the settings of the milk dispensing knob, the given amounts of CAPPUCCINO and LATTE may
be different
– detailed description of setting the quantity and time can be found in the further part of the manual
