EN 02
03 EN
SPECIFICATION
DIAGRAM
POWER ON
POWER OFF
Connection Technology: Bluetooth
Frequency Range: 2.4 GHz
Output Power Category: Class 2
Bluetooth Protocol: HFP/ HSP/ A2DP/ AVRCP
Bluetooth Range: Up to 30 feet
Power Supply: Li-Po 170 mAh
Working Current: 15 mA (MAX)
Charge Voltage: DC 5.0 V
Long press the button “
” for about 3 s. It
will power on automatically with red indica-
tor light staying on for 1 s. Then the red and
EOXHLQGLFDWRUOLJKWÁDVKHVDOWHUQDWHO\
Long press the button “
” for about 3s, and
the red indicator light will stay on for 1 s.
Then it powers off automatically.
1. Power ON/ OFF; Pause/ Play; Answer/
Hang Up
2. Microphone
3. Next Song/ Volume Up
4. Previous Song/ Volume Down
5. USB Charging Port
6. Indicator Light
7. Audio Output Port
1
7
2
6
3
4
5
