mPTech myPhone 2220 User Manual

EN © 2022 mPTech. All rights reserved. 2220
21
long time, it turns off the phone or, if it is switched off,
turns it on.
8
<*> button
Press the Menu key to lock or unlock the phone. Decreases
volume in multimedia apps When writing an SMS, it
displays symbols for insertion into the content.
9
<#> button
Switches between audio modes and character input modes
for texting, increases the volume in multimedia
applications.
10
External speaker
Loudspeaker for system sounds, ringtones, music.
11
Phone keypad
Buttons allowing you to dial a phone number and, in the
text message mode, type letters and digits.
12
LED
Diode is used as a torch.
13
MicroUSB port
When connected, the charger enables recharging the
battery. You can transfer data (photos, videos, music) when
you connect it to your computer.
14
Headphone port
minijack 3.5 mm
Allows you to connect headphones to the phone, so you
can listen to the radio (they improve the quality of
reception - they work as an additional antenna), music, as
well as make calls (when headphones are equipped with a
microphone).
15
Gap
Allows to take off a cover of the phone.
Turning the phone on/off
To turn the phone on/off press and hold the <Red handset> button. If you are
prompted to enter a PIN code as soon as the phone is switched on, enter the PIN code
(you will see it as ****) and press the [Menu] key.
Inserting SIM, memory cards and the battery
If the phone is switched on - switch it off. Remove the back cover of the phone - use
your fingernail to raise it using the gap in the case. Insert the SIM card - It is supposed
to be placed with its gold contacts facing down, the way in which the slot is embossed.
Insert the memory card - to open the cover of the card reader slide it gently up. Insert
the microSD memory card with its gold contacts facing down, the way in which the
slot is embossed. Close the flip by sliding it delicately downwards. Insert the battery
so that its gold contacts touch the tripple connector in the phone bay. Put on and
gently press down the cover until you hear the click of the latches. Make sure the cover
is well attached.
Charging the battery
Connect the microUSB plug of the charger to the charging connector on the phone,
then plug the charger into a power outlet.
*Attention: Improper connection of the charger cable can cause serious damage to the
phone and/or the charger. Damage caused by improper use of the phone and its
accessories is not covered by the warranty.
The icon (or similar) will appear during charging and when the battery is fully
charged. When charging is complete unplug the charger from the power outlet. Unplug
the cable from the socket on the phone.
2. Using the basic functions
Keypad lock
To lock the keyboard press [Menu] > <*> To unlock the keyboard press [Unlock] > <*>.
