SAVE THESE INSTRUCTIONS
Maximum Capacity (tons)
Stroke (in.)
Working Range (in.)
50
9
0~33 7/8
Warning
1. Do not overextend the Ram. (Do not over the Warning Line on the Piston of Ram.)
2. Do not overload the capacity.
3. Do not attempt to operate pump unless the Breather Valve both on pump and gauge are open.
4. Do not Press unless the Hand Winch is release.
Specification
Ram
Upper Beam
Press Table
Hand Winch
Frame Post
Base Support
Pneumatic Pump
Gauge
Air Switch
