Page 23 mrcool.com
Outdoor Unit Installation
Step 3: Anchor outdoor unit - Multi-Zone
Outdoor Unit Dimensions:
inches (millimeters)
Mounting Dimensions:
inches (millimeters)
Width (A) Depth (B)
33.27 in x 27.6 in x 14.3 in
(845 mm x 701 mm x 363.22 mm)
13.8 in
(351 mm)
37.5 in x 52.5 in x 16.4 in
(953 mm x 1334 mm x 417 mm)
15.9 in
(404 mm)
37.2 in x 31.9 in x 16.4 in
(945 mm x 810 mm x 417 mm)
37.2 in x 31.9 in x 16.4 in
(945 mm x 810 mm x 417 mm)
26.5 in
(673 mm)
15.87 in
(403 mm)
26.5 in
(673 mm)
15.87 in
(403 mm)
Fig. 4.9
W
H
Fig. 4.8
A
B
D
Fig. 4.7
W
H
Before installing a condenser on a wall, make
sure that the wall is made of solid brick,
concrete, or of similarly strong material.
The wall must be able to support at
least four times the weight of the unit.
If you will install the unit on a wall-mounted
bracket, do the following:
1.
2.
Pre-drill the holes for the expansion bolts.
3. Clean dust and debris away from holes.
4. Place a washer and nut on the end of each
expansion bolt.
5. Thread expansion bolts through holes in
mounting brackets, put mounting brackets in
position, and hammer expansion bolts into the
wall.
25.2 in
(640 mm)
21.26 in
(540 mm)
Mark the position of bracket holes based on
dimensions in the Unit Mounting Dimensions
chart.
