MSA Cylinder Valve - Page 2

2
TAL 807 (L) Rev. 6 - 10042832
Item Part No. Description
809872 3AL Aluminum, 45 cu ft.*
469619 Hoop-wound, 45 cu ft.
8
07586 L-30 Stealth Carbon-wrapped
816115 L-30+ Stealth Carbon-wrapped, 60 cu ft.
807587 H-30 Stealth Carbon-wrapped, 45 cu ft.
807570 H-45 Stealth Carbon-wrapped, 66 cu ft.
10035644 H-45 Low-Profile, Stealth Carbon-wrapped, 66 cu ft.
1 807588 H-60 Stealth Carbon-wrapped, 88 cu ft.
814806 3AL Aluminum, 45 cu ft.*
81119 Hoop-wound, 45 cu ft.
816970 L-30 Stealth Carbon-wrapped
816974 L-30+ Stealth Carbon-wrapped, 60 cu ft.
816972 H-30 Stealth Carbon-wrapped, 45 cu ft.
816973 H-45 Stealth Carbon-wrapped, 66 cu ft.
10044832 H-45 Low-Profile, Stealth Carbon-wrapped, 66 cu ft.
816971 H-80 Stealth Carbon-wrapped, 88 cu ft.
2 804922 Warning Label
3 471368 Label Lot No.
4 492845 Caution/Warning Label (3000 psig)
488894 Valve Assembly (2216 psig)
5 494884 Valve Assembly (3000 psig)
488899 Valve Assembly (4500 psig)
6 80416 Cylinder Valve Inlet Tube
68542 O-Ring (2216 psig)
7 633550 O-Ring (3000 psig)
630926 O-Ring (4500 psig)
68550 Safety Plug (2216 psig)
8 495636 Safety Plug (3000 psig)
473254 Safety Plug (4500 psig)
9 68543 Drill Hex Head Socket Screw (Prior Design)
10
488858 Valve Insert Assembly
15339 Valve Insert Assembly
11
14438 Valve Stem (Prior Design)
488859 Valve Stem (Current Design)
12 488860 Valve Stem Washer
13 628976 O-Ring (Current Design)
14 488862 Packing Gland (Current Design)
15 91728 Hand Wheel
16 83831 Spring
17 83731 Lock Nut
18 94906 Protector Cap
Item Part No. Description
488771 Valve Body (4500 psig) (Current Design)
19
488772 Valve Body (2216 psig) (Current Design)
4
95743 Valve Body (3000 psig) Valve Body (180°)
Valve Body (Prior Design)
95019
Air Pressure Gauge (2216/3000 psig)
20
(Prior Design)
95278 Air Pressure Gauge (2216/3000 psig)
473250 Air Pressure Gauge (4500 psig)
21 66835 O-Ring (Prior Design)
22 454544 Gland Ring (Prior Design)
23
801131 Gauge Guard
801140 Gauge Guard (Prior Design)
KITS
482225 Blow Out Disc Kit (2216 psig)
24 482226 Blow Out Disc Kit (4500 psig)
494928 Blow Out Disc Kit (3000 psig)
25 473957 Packing Gland Kit (Prior Design)
CYLINDER VALVE ASSEMBLIES (LOW PRESSURE)
809872
45 CU. FT. Aluminum (2216 psig) (Rated
30 Min.) (Current)
469619
45.5 CU. FT. Hoop Wound Aluminum
(2216 psig) (Rated 30 Min.) (Current)
807586
66 CU. FT. Composite Carbon (2216 psig)
(Rated 30 Min.) (Current)
816115
60 CU. FT. Composite III Carbon
(3000 psig) (Rated 30 Min.) (Prior)
CYLINDER AND VALVE ASSEMBLIES (HIGH PRESSURE)
807587
45 CU. FT Composite Carbon (4500 psig)
(Rated 30 Min.) (Current)
807570
66 CU. FT Composite Carbon (4500 psig)
(Rated 45 Min.) (Current)
10035644
66 CU. FT. Composite Carbon (4500 psig)
(Rated 45 Min.) (Current)
807588
88 CU. FT Composite Carbon/Fiberglass
(4500 psig) (Rated 60 Min.) (Current)
CYLINDER VALVE COMPONENTS
