3 Installation
Disassembling SingleLine Gauge
For disassembling the SingleLine gauge, a Torx spanner and a small screw driver are required.
(1) Unscrew the back cover of the SingleLine gauge with
a Torx T10 spanner.
(2) Lift the back cover.
(3) Remove the U-clip with a small screw driver.
(4) Pull the SingleLine manifold out.
