6 INSTALLATION INSTRUCTIONS
MSD • WWW.MSDPERFORMANCE.COM • (915) 855-7123 • FAX (915) 857-3344
GEAR SHIFT
In the Gear Shift selection the user can set items such as launch and shift delay so that the system will not
have a false shift detected immediately after launch or a shift should there be an rpm drop for any other reason.
Launch Delay: The amount of time in seconds after the launch that the system will ignore an rpm drop to
prevent false shift detection. This can be set from 0.00 to 10.00 in .01 second increments.
Shift Delay: The amount of time in seconds after sensing a shift that the system will ignore an rpm drop to
prevent false shift detection. This can be set from 0.00 to 10.00 in .01 second increments.
1->2 Shift: By setting the rpm drop the user tells the system how to sense when the car is being shifted
during a run. The setting is controlled by a drop down list with rpm from 200 – 1,500 or can be set
to be activated by a Step Retard wire instead. The number of shifts that is shown is controlled by the
number of gears the system is set to in the Settings – General tab.
SHIFT LIGHT
Using the Shift Light controls opens a variety of options designed to help make sure the light is exactly as
desired. The shift light setting can be set by single rpm increments. In this control tab, each value can be
entered to the exact rpm desired and the light’s intensity can be adjusted so that it is visible without blinding.
The number of gears that appear on this tab will be auto-populated by the program after the number of gears
is set in the general settings. This can also be used with a relay as a transmission shifter. The maximum
current for this circuit is 3 amps.
Light Intensity: This percentage setting controls brightness of the shift light for easy use in both day and
night racing. If being used for anything other than shift light control, the intensity must be 100%.
Power-On Test: Normally set to on but can be turned off if desired. The power-on test turns the shift light on
as soon as the controller receives power to show that the circuit is complete and working.
Launch Light: The Shift Light will turn on if the engine rpm is between the launch low limit and the launch
high limit. The light will blink if rpm is above the launch high limit.
Gear 1-5: A setting can be adjusted for each individual shift. To do this enter the engine RPM that should
turn the Shift Light ON for each gear.
OUTPUT SWITCH
When the switch is activated it will supply ground to a circuit in order to turn an item on by time and/or rpm.
The circuit can maintain up to 2 continuous amps. If more than 2 amps is needed a relay is recommended,
PN 8961.
To activate or deactivate this circuit the system must see a programmed time and/or rpm setting which is
programmed in the Settings – Output. Using both On and Off values will set a window to control the switch.
The output will only be activated while within the set window and will be deactivated as soon as one or both
sides of the windows are not met. All parameters must be met for the output switch to be activated. For
example, if values are entered for both RPM On and Activation Point (timed on) then both of those values
must be reached before the switch is activated. The rpm function becomes active and the time function begins
counting after the Dark Blue launch wire is released.
Note: If using the time activation function a duration MUST be set above 0.00 or the switch will not be
activated by time.
IGNITION TIMING
The user can set the timing from 0 - 60° BTDC. However, actual timing will never advance past the maximum
timing reference nor will the timing retard more than 30° from the max timing reference. MAX and MIN timing
lines will be displayed for convenient reference in the main engine timing tab. (Those lines can be turned off
by unchecking them in the upper left column.)
Note: When using EFI the max timing reference and the main timing must be the same number.
