3-24
MS-6737 ATX Mainboard
PC Health Status
This section shows the status of your CPU, fan, overall system status,
etc. Monitor function is available only if there is hardware monitoring mecha-
nism onboard.
Vcore, +3.3V, +5.0V, +12V, -12V, -5.0V, Battery Voltage, System/CPU
Fan Speed, System/CPU Temperature
These items display the current status of all of the monitored hardware de-
vices/components such as system voltages, temperatures and fan speeds.
CPU Fan Beep
This setting allows you to monitor the operation of the CPU fan. Setting to
Enabled will activate the warning beep once the system detects the malfunc-
tion/halt of the CPU fan.
