Gettng Started ▍
MS-7576
1-3
Gettng Started ▍
MS-7576
Connectors
Back panel
1 PS/2 port
1 Optcal S/PDIF-Out port
1 VGA port
1 DVI-D port
1 HDMI port
1 IEEE1394 port (optonal)
6 USB 2.0 ports
1 eSATA port
1 LAN jack
6 󰘱exble audo jacks
On-Board Connectors
3 USB 2.0 connectors
1 IEEE1394 connector (optonal)
1 SPDIF out connector
1 CD-In connector
1 Front Panel Audo connector
1 Chasss Intruson Swtch connector
1 Seral connector
1 TPM connector
1 OC swtch
1 Power LED Button
1 Reset LED Button
1 Clear CMOS Button
Slots
1 PCI Express x16 slot
3 PCI Express x1 slots
2 PCI slot, support 3.3V/ 5V PCI bus Interface
Form Factor
ATX (30.5cm X 24.4 cm)
Mountng
9 mountng holes
■
-
-
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
■
■
