16
Specifications
Continued from previous page
Internal Connectors
y
1x 24-pin ATX main power connector
y 1x 8-pin ATX 12V power connector
y 4x SATA 6Gb/s connectors
y 2x M.2 slots
y 1x USB 3.1 Gen1 connector (supports additional 2 USB 3.1
Gen1 ports)
y 1x USB 2.0 connector (supports additional 2 USB 2.0 ports)
y 1x 4-pin CPU fan connector
y 1x 4-pin Water Pump connector
y 1x 4-pin system fan connector
y 1x Front panel audio connector
y 2x System panel connectors
y 1x Chassis Intrusion connector
y 1x 4-pin RGB LED connector
y 1x Clear CMOS jumper
y 1x TPM module connector
I/O Controller NUVOTON NCT6797 Controller Chip
Hardware Monitor
y
CPU/System temperature detection
y CPU/System fan speed detection
y CPU/System fan speed control
Form Factor
y
Mini-ITX Form Factor
y 6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)
BIOS Features
y
1x 128 Mb flash
y UEFI AMI BIOS
y ACPI 6.1, SMBIOS 2.8
y Multi-language
Continued on next page
