37
Overview of Components
Important
y
The JRGB1 connectors support 5050 RGB LED strip (12V/G/R/B) with the maximum
power rating of 3A (12V).
y
Please keeping the LED strip shorter than 2 meters to prevent dimming.
y
Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing the LED strip.
y
Please use MSIs software to control the extended LED strip.
JRGB1: RGB LED connector
This connector allows you to connect the 5050 RGB LED strips 12V.
1
JRGB1
Extension cable
5050 RGB LED strips 12V
1
1 +12V 2 G
3R4 B
To Next Page
