MSI 845G Max - Quick Components Guide

Chapter 1
1-6
Quick Components Guide
Component Function Reference
DDR1~3 Installing DDR SDRAM modules See p. 2-5~2-6
Socket 478 Installing CPU See p. 2-2~2-3
CPUFAN1 Connecting to CPUFAN See p. 2-15
SYS_FAN1 Connecting to SYSTEM FAN See p. 2-15
PWR_FAN1 Connecting to POWER SUPPLY FAN See p. 2-15
ATX Power Supply Installing power supply See p. 2-7
JPW1 Connecting to 12V power connector See p. 2-7
IDE1 & IDE2 Connecting to IDE hard disk drive See p.2-14
FDD1 Connecting to floppy disk drive See p.2-13
JUSB1/2 Connecting to USB interfaces See p. 2-19~2-20
PCI Slot 1~6 Installing PCI expansion cards See p. 2-26
AGP Slot Installing AGP cards See p. 2-25
CNR Slot Installing CNR cards See p. 2-26
JBAT1 Clearing CMOS data See p. 2-24
JFP1/2 Connecting to case See p. 2-17
IR1 Connecting to IR module See p. 2-16
JAUDIO1 Connecting to audio connector See p. 2-18
JDB1 Connecting to D-Bracket™ See p. 2-22
COM 2 Connecting to COM port See p. 2-10
JBT1 Connecting to blue tooth module See p. 2-16
JDB1 Connecting to D-Bracket™ 2 See p. 2-22
JCASE1 Connecting to chassis intrusion switch See p. 2-23
JGS1 Connecting to power saving switch See p. 2-23
CD_IN1 Connecting to CD-ROM audio connector See p. 2-21
