MSI 845G Max - DIMM Module Combination; Installing DIMM Modules

Chapter 2
2-6
Install at least one DIMM module on the slots. You can install either
single- or double-sided modules to meet your own needs.
Intel
®
82845G chipset supports a maximum of 4 memory banks. DIMM 1
alone occupies two memory banks; the other two banks are shared by DIMM
2 & DIMM 3. Therefore, you must follow the table below to install memory
modules:
DIMM Module Combination
1. Insert the DIMM memory module vertically into the DIMM slot. Then push
it in.
2. The plastic clip at each side of the DIMM slot will automatically close.
Installing DIMM Modules
Volt
notch
The DDR DIMM has only one notch on the center of the module. The
module will only fit in the right orientation.
S: Single Side D: Double Side
Combination Slot
1 2 3 4 5
DIMM 1
S/D S/D S/D S/D S/D
DIMM 2
D S S
DIMM 3
D S S
Total Memory
64MB ~ 2GB
