Realtek Audio
MS-7623
Appendix A
A-7
Realtek Audio
MS-7623
Appendix A
and Bass Management functions can not be enabled at the same time.
Con󰘰guration Panels: On the bottom of the top panel, there is a row of buttons. When
any of the buttons are activated (except the "Power" button), the bottom panel ex-
pands to show the selected panel.
Power Button: When the Power button is activated, Adeck will hide itself in the system
tray.
Bottom Panel
The Bottom Panel is beneath the top panel. The contents of the Bottom Panel are
dependent upon the button that activated to it. Even if the Bottom Panel is already
expanded, the contents can still be changed by selecting another button from the bot-
tom of the Top Panel.
Speaker Con󰘰guration Panel: As Page A-8 shows, it contains the channel con󰘰gura-
tion and output volume control. To test a speaker to see if it is connected, single-click
on the desired speaker. To test all speakers, just click the Test button.
Mixer Con󰘰guration Panel: As Page A-10 shows, it contains the basic Playback Mixer
and Recording Mixer volume controls. Additionally, the user can select which playback
or recording device to be active.
E󰘯ects Con󰘰guration Panel: As Page A-11 shows, there are two sound enhancement
functions that can be selected: “Equalizer” or “Bass Management”.
Jack Con󰘰guration Panel: As Page A-13 shows, the user can re-task every jack’s us-
age and active jack detection. The user can also con󰘰gure the headphone to receive
the same audio signals as the front speakers.
S/PDIF Con󰘰guration Panel: As Page A-15 shows, the user can con󰘰gure the S/PDIF
related control.
System Information Panel: As Page A-16 shows, the user can view the system
information and set the preferred language. Additionally, the user can program the hot
keys.
