Mixer Conguration Panel
On the Mixer Conguration Panel, there are four mixer devices that can be selected:
playback, microphone, line in and front microphone. Below shows the Playback Mixer.
Each of the Playback items has a volume, balance and mute control. The user can
also select the default playback device from a drop-down menu. User could redirect
the analog input sources (Microphone, Line In, Front Microphone etc.) to line out by
checking this feature.
Playback Control Balance
Default Playback Device
MuteVolume
Next Page
On the Recording Control, all possible input devices are shown. Below shows the Micro-
phone. Each of the Recording Control items has a volume, balance and item select. On
the bottom-left side of this page, there are Mic 20db boost control and Front Mic 20db
boost control check boxes. User could enlarge the recording sound by checking on this
feature. There is also a peak meter to show the volume of the audio input.
Recording Control Balance
Default Playback Device
Mute Volume
Click here to return to playback control
Peak Meter
Mic 20db Boost
To Next Page
