MSI A88X-G43 Series User Manual

Chapter 1
1-5 Getting Started
Internal
Connectors
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
8x SATA 6Gb/s connectors
3x USB 2.0 connectors (supports additional 6 USB 2.0 ports)
1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
1x 4-pin CPU fan connectors
2x 4-pin system fan connectors
1x 3-pin system fan connector
1x Clear CMOS jumper
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Serial port connector
■
■
■
■
■
■
■
■
■
■
■
■
■
■
I/O
Controller
Fintek 71889 Controller Chip■
Hardware
Monitor
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
■
■
■
BIOS
Features
64 Mb 󰘱ash
UEFI AMI BIOS
ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
Multi-language
■
■
■
■
Special
Features
Military Class 4
Military Class Essentials
OC Genie 4
Click BIOS 4
AMD CrossFire
AMD Dual Graphics
4K UHD Support
3 Display Outputs
PCI Express Gen 3
USB 3.0
SATA 6Gb/s
Command Center
Fast Boot
Live Update 5
M-Flash
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
Software Drivers
MSI
Command Center
Super Charger
Live Update 5
Fast Boot
7-ZIP
Norton Internet Security Solution
Trend Micro SafeSync
■
■
-
-
-
-
■
■
■
Form
Factor
ATX Form Factor
12 in. x 8.9 in. (30.5 cm x 22.5 cm)
■
■
