MSI B250MPRO-VD - Jfp1, Jfp2: 前置面板接口

12
󶳧󱝾󴘭󸵅
JUSB1~2: USB 2.0 󳰛󱿂
󸴐󱛩󳰛󱿂󱭩󸚞󳜂󸴗󳰛󱴚󶷉󹪸󴋃󱘔󵵙 USB 2.0 󶔏󱿂
1
2 10
9
1 VCC 2 VCC
3 USB0- 4 USB1-
5 USB0+ 6 USB1+
7 Ground 8 Ground
9 No Pin 10 NC
JFP1, JFP2: 󱴚󶷉󹪸󴋃󳰛󱿂
󸴐󱛩󳰚󱿂󸴗󳰚󱴙󶷉󹪸󴋄󱘔󵵙󳐴󱯃󲃅 LED 󵉈
1
2 10
9
JFP1
1 HDD LED + 2 Power LED +
3 HDD LED - 4 Power LED -
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
1
JFP2
1 Speaker - 2 Buzzer +
3 Buzzer - 4 Speaker +
HDD LED
RESET SW
HDD LED
HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
JFP1
