Safety Information Specifications
Specifications
CPU
Supports 9th/8th Gen Intel
®
Core™ / Pentium
®
Gold / Celeron
®
processors for LGA 1151 socket
* Please go to www.intel.com for more compatibility
information.
Chipset Intel
®
B365 Chipset
Memory
y 2x DDR4 memory slots, support up to 32GB
y Supports DDR4 2666/ 2400/ 2133 MHz
y Supports Dual-Channel mode
y Supports non-ECC, un-buffered memory
y Supports Intel
®
Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on
compatible memory.
Expansion Slots
y 1x PCIe 3.0 x16 slot
y 2x PCIe 3.0 x1 slots
Onboard
Graphics
y 1x VGA port, supports a maximum resolution of
2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz (B365M
PRO-VD, B365M PRO-VH, B365M PLUS)
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz (B365M PRO-VD)
y 1x HDMI™ port 1.4, supports a maximum resolution of
4096x2160@30Hz (B365M PRO-VH, B365M WIND, B365M
PLUS)
* No display support when using the processor model with
suffix F
Storage
Intel
®
B365 Chipset
y 6x SATA 6Gb/s ports*
y 1x M.2 slot (Key M) (B365M PRO-VD, B365M PRO-VH,
B365M PLUS)
 Supports up to PCIe 3.0 x4 and SATA 6Gb/s
 Supports 2242/ 2260/ 2280 storage devices
 Intel
®
Optane™ Memory Ready**
* The SATA1 port will be unavailable when an M.2 SATA SSD
module has been installed in the M.2 slot.
** Before using Intel
®
Optane™ memory modules, please
ensure that you have updated the drivers and BIOS to the
latest version from MSI website.
Continued on next page

MSI B365M PLUS Specifications

General

Form Factor	Micro ATX
Chipset	Intel B365
Socket	LGA 1151
Memory Slots	4 x DIMM
Maximum Memory	64 GB
Memory Speed	DDR4 2666/2400/2133 MHz
Audio	Realtek ALC887
LAN	Realtek 8111H Gigabit LAN
RAID Support	RAID 0, 1, 5, 10
Storage Interface	6 x SATA 6Gb/s, 1 x M.2
USB Ports	6 x USB 3.1 Gen1, 6 x USB 2.0
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
